SLA 3D Printing Service
Experience the next level of 3D printing with our state-of-the-art SLA technology. Whether you’re prototyping a new design or crafting intricate, high-detail components, our SLA 3D printing service ensures your vision is brought to life with precision, clarity, and an exceptional surface finish. From concept to creation, we deliver perfection in every layer.
What is SLA 3D Printing?
SLA (Stereolithography) 3D printing is a type of additive manufacturing technology that uses a light-sensitive liquid resin and a laser to create highly detailed and accurate 3D objects.
By using this technology, an SLA 3D printer transforms liquid resin into precise 3D objects with high accuracy and fine detail.
ProtoTi’s SLA 3D printing services deliver high-resolution, finely detailed parts with smooth surfaces, ideal for both end-use and low-volume manufacturing, as well as rapid prototyping. We offer a range of resins, including standard, tough, and transparent options, to meet your on-demand manufacturing needs.
ProtoTi 3D Printing Specifications
| Name | Min. Wall Thickness | Max. Build Size | Tolerance | Support Structures | Lead time |
|---|---|---|---|---|---|
| Industrial SLA | 0.6 mm | 1650×760×580 mm | ±0.2 mm | Yes | from 2 business days |
SLA 3D Printing Parts Using Various Materials
Standard Resin(White)
Achieve clean, detailed, and professional-grade prints with our Standard White Resin 3D Printing service. Perfect for prototypes, models, and intricate designs, this resin offers a smooth, high-quality finish and exceptional precision. Its durability and aesthetic appeal make it an ideal choice for a wide range of applications.
Tough Resin(Green)
Discover the strength and durability of our Tough Resin (Green) 3D Printing service. Engineered for robust performance, this resin is ideal for functional prototypes and end-use parts requiring high impact resistance. With a smooth finish and excellent detail resolution, it’s perfect for demanding applications that need both toughness and precision.
Tough Resin(Black)
Experience superior durability with our Tough Resin (Black) 3D Printing service. Designed for high-stress applications, this resin is perfect for functional prototypes and end-use parts that require exceptional strength and impact resistance. Enjoy a sleek, professional finish with precise detailing, making it ideal for both practical and aesthetic projects.
Translucent Resin
Achieve stunning clarity and precision with our Translucent Resin 3D Printing service. Ideal for prototypes, models, and parts requiring a clear or semi-transparent finish, this resin delivers exceptional detail and a smooth surface. Perfect for applications where visual inspection and aesthetics are critical.
Transparent Resin
Experience crystal-clear precision with our Transparent Resin 3D Printing service. Perfect for creating prototypes, models, and parts that require a see-through finish, this resin offers exceptional clarity and detail. Ideal for applications where transparency and aesthetic quality are paramount.
High Temperature Resin(Beige)
Our High Temperature Resin (Beige) 3D Printing service delivers outstanding heat resistance, making it ideal for applications that require thermal stability. Perfect for functional prototypes and end-use parts exposed to high temperatures, this resin ensures durability and precise detailing, maintaining performance and integrity under extreme conditions.
High Temperature Resin(Grey)
Our High-Temperature Resin (Grey) 3D Printing service offers superior thermal resistance, perfect for applications requiring high heat tolerance. Ideal for functional prototypes and end-use parts, this resin maintains durability and precision even under extreme conditions, ensuring reliable performance and detailed finishes.
SLA 3D Printing Material Specifications
| Material Name | Description | Max. Build Size | Elongation at Break (%) | Flexural Strength (MPa) | HDT@0.46 MPa (℃) |
|---|---|---|---|---|---|
| Standard Resin | White, ABS-like | 1650 x 780 x 550 mm | 7% | 47 MPa | 46℃ |
| Tough Resin | White, Light Green, Black, ABS-like | 780 x 780 x 550 mm | mm | 60 MPa | 60℃ |
| Translucent Resin | Translucent, PC-like | 780X780X 780X 550mm | 7% | 67 MPa | 47℃ |
| Transparent, Resin | Transparent, Clear, PC-like | 780X 780X 550 mm | mm | 67 MPa | 47℃ |
| High Temperature Resin | White, ABS-like | 780X780X 780X 550mm | mm | 136 MPa | 220℃ |
SLA 3D Printing PROS & CONS
Pros
High Precision and Detail:
SLA 3D printing excels in producing intricate details and fine features, making it ideal for applications that require high accuracy.
Smooth Surface Finish:
The process results in parts with smooth surfaces right out of the printer, often requiring minimal post-processing compared to other 3D printing methods.
Excellent for Complex Geometries:
SLA is particularly effective for creating complex shapes, internal channels, and intricate designs that would be challenging with other manufacturing techniques.
Rapid Prototyping:
Ideal for quickly producing functional prototypes, SLA allows designers to iterate and refine designs before moving to mass production.
Cons
Material Fragility:
Standard SLA resins can be brittle, making them less suitable for parts that require high impact resistance or flexibility unless specialized resins are used.
Post-Processing Required:
SLA parts require post-processing, such as cleaning with isopropyl alcohol and UV curing, which adds time and effort to the overall process.
SLA 3D Printing FAQs
SLA (Stereolithography) 3D printing is a technology that uses a laser to cure and harden liquid resin layer by layer, creating highly detailed and precise 3D objects with smooth surface finishes.
SLA 3D printing uses photopolymer resins, available in various types such as standard resin, tough resin, flexible resin, and transparent resin, each suited for different applications.
SLA 3D printing is known for its high accuracy, typically achieving layer heights as small as 25 microns, which allows for very fine details and smooth surfaces in the final printed objects.
SLA 3D printing is ideal for creating prototypes, intricate models, functional parts, custom jewelry, dental models, and more. It’s suitable for both low-volume manufacturing and end-use parts.
The durability of SLA-printed parts depends on the type of resin used. Standard resin offers good all-around properties, while tough resin is designed for high impact resistance, and flexible resin offers elasticity.
After printing, SLA parts typically need to be rinsed in isopropyl alcohol to remove excess resin, followed by a post-curing process under UV light to fully harden the parts and improve their mechanical properties.
The time required for SLA 3D printing depends on the complexity, size, and layer resolution of the model. Printing can take anywhere from a few hours to over a day for more complex parts.
Common file formats for SLA 3D printing include STL, OBJ, and STEP. These files should be prepared with the correct orientation, supports, and resolution to ensure optimal printing results.
Yes, SLA 3D printed parts can be sanded, primed, and painted for a smooth finish. Additional post-processing options include polishing, dyeing, and applying a clear coat for enhanced durability and appearance.
SLA offers superior surface quality, fine details, and higher resolution compared to FDM (Fused Deposition Modeling) and SLS (Selective Laser Sintering). However, it may be more expensive and slower, and the material options are more limited.
Other 3D Printing Capabilities from ProtoTi
SLA
Stereolithography
- Visual part prototyping. High resolution. Low cost.
- Dimensional accuracy of ±0.2% with a lower limit of ±0.2mm.
- Lead times from 2 business days
SLS
Selective Laser Sintering
- Functional prototyping. Low-run production.
- Dimensional accuracy of ±0.3% with a lower limit of ±0.3mm.
- Lead times from 3 business days
MJF
Multi Jet Fusion
- Functional prototyping. Low-run production.
- Dimensional accuracy of ±0.3% with a lower limit of ±0.3mm.
- Lead times from 3 business days
SLM
Selective Laser Melting
- Metal parts rapid prototyping. Production grade.
- Dimensional accuracyDimensional accuracy of ±0.2% with a lower limit of ±0.2mm.
- Lead times from 4 business days of ±0.3% with a lower limit of ±0.3mm.
FDM
Fused Deposition Modeling
- Plastic parts rapid prototyping. Low cost.
- Dimensional accuracy of ±0.29 with a lower limit of ±0.2mm.
- Lead times from 4 business days
DLP
Digital Light Processing
- Resin parts rapid prototyping. High details.
- Dimensional accuracy of ±0.2% with a lower limit of ±0.2mm.
- Lead times from 4 business days
